Request for .275 Rigby/7mm Mauser Load Data

[jbirdwell]

I just picked up one of the Ruger #1’s in 275 Rigby and was wondering if I can use published load date for the 7x57. I’ll be using 7x57 brass until I can find some of the 275 brass.



[hoytcanon]

I just picked up one of the Ruger #1’s in 275 Rigby and was wondering if I can use published load date for the 7x57. I’ll be using 7x57 brass until I can find some of the 275 brass.

One of my 7X57's is a No.1-A and I use the load that I listed earlier in this thread.



[franzfmdavis]

Well, the Rigby is off to JJ to open up the free bore so that I can chamber bullets heavier than 140g. Once I get it back, I should be able to use all of this great data that you all have been so kind to share!



[dchamp]

Did you try and measure the cartridge's over all length to the lands with Hornady’s o.a.l gauge. With that you can keep a bullet from jamming by seating the bullet deeper.



[Clodo Ferreira]

I don´t know why riflemakers want to improve on perfection...The original Mauser chamber configuration, set up for a 173 grs round nose full metal jacket military bullet, can handle the 140 and even lighter-shorter bullets as well as that original one. More so if the free bore section diameter is dimentioned correctly. The same with the original 1:220 mm (1:8,66...") rifling twist. Good for anything.



[grand veneur]

I never understand why people try to improve old cartridges. These old cartridges have proven themselves for a certain purpose, and that is how they should continue to be used. Anyone looking for more performance has the option of using many other cartridges available nowadays.



[Sika98k]

Those are just standardized recommendations... my load in two of my current rifles is 3.070" and there is still a jump. You have to determine what is best for your own rig.

Sure, I agree with you. The point I was making is that all the loads have the same overall length with the one exception.
My Rigby shoots Nosler Partitions 175gr perfectly well. H414,40gr. There is one bullet stuck on the skin on the opposite side of an oryx I shot.



[wswolf]

Since the 7x57 and 7-08 are nearly identical in case capacity, I used Hodgdon 7-08 data to work up loads for my Model 70. Since throat dimensions, and therefore pressures, vary considerably with individual rifles I took advice from John Barsness: "... I tend to load to a certain velocity level rather than a specific charge weight. With appropriate powders, velocity correlates strongly with pressure. In barrels 21-24 inches long, 2800-2900 fps with bullets in the 140-grain range is easily obtainable with modern powders, 2600-2700 fps with bullets in the 160-grain range and 2500-2600 with 175s." "But the powder charge required to reach those levels varies considerably from rifle to rifle". (The Big Book of Gun Gack, Barsness, 2015)

My best results were with 145 LRX and StaBall 6.5 at 2940 fps or 150 Nosler Ballistic Tips with StaBall 6.5 or Reloder 26 at 2850 fps.



[benchracer]

Since the 7x57 and 7-08 are nearly identical in case capacity, I used Hodgdon 7-08 data to work up loads for my Model 70. Since throat dimensions, and therefore pressures, vary considerably with individual rifles I took advice from John Barsness: "... I tend to load to a certain velocity level rather than a specific charge weight. With appropriate powders, velocity correlates strongly with pressure. In barrels 21-24 inches long, 2800-2900 fps with bullets in the 140-grain range is easily obtainable with modern powders, 2600-2700 fps with bullets in the 160-grain range and 2500-2600 with 175s." "But the powder charge required to reach those levels varies considerably from rifle to rifle". (The Big Book of Gun Gack, Barsness, 2015)

My best results were with 145 LRX and StaBall 6.5 at 2940 fps or 150 Nosler Ballistic Tips with StaBall 6.5 or Reloder 26 at 2850 fps.

The Barsness guidelines are very good guidelines to follow. Like you, I have found 7mm-08 data to be useful as a sanity check for my 7x57 (in terms of overall ballistic potential).

However, 7x57 case capacity is VERY different from 7-08 case capacity. Depending which makes of brass are being compared, 7x57 has anywhere from around 5.5% to 11%+ greater case capacity than 7-08. In general, because of its greater case capacity and longer neck, 7x57 works well with slower burning powders and heavier bullets than does 7-08.



[franzfmdavis]

Did you try and measure the cartridge's over all length to the lands with Hornady’s o.a.l gauge. With that you can keep a bullet from jamming by seating the bullet deeper.

I haven't tried that because I don't have such a gauge currently. Its with JJ now.



[benchracer]

I haven't tried that because I don't have such a gauge currently. Its with JJ now.

If you want to do this, you don't need special tools. You can use the following materials:

Cheap Universal Cleaning Kit (the kind that has 3-piece cleaning rods and plastic cleaning jags)
Painter's Tape
Wooden pencil (sharpened)
Single edge razor blade

How To:

1. Ensure firearm us unloaded and chamber is empty.
2. Close bolt.
3. Assemble cleaning rod.
4. Select largest diameter cleaning jag (typically made of plastic) that will fit in the bore.
5. Using the razor blade, cut the spear tip off flush with the face of the jag.
6. Install cleaning jag on the cleaning rod
7. Insert the end of the cleaning rod with the jag into the rifle muzzle and feed cleaning rod into barrel until it makes contact with the bolt face and stops.
8. Beginning just ahead of the muzzle, apply a 6 inch length of painters tape, gradually retracting the cleaning rod from the muzzle as you smooth the painters tape toward the end of the cleaning rod that is in the barrel.
9. After applying the painters tape, re-insert the cleaning rod into the barrel until the jag is touching the bolt face.
10. While firmly holding the cleaning rod and jag against the bolt face with one hand, use the other hand to hold the single edge razor blade, with the flat side of the blade flush with the end of the muzzle and the cutting edge of the razor blade resting against the painters tape that has been applied to the cleaning rod.
11. Use the hand holding the cleaning rod to rotate the cleaning rod, scoring the painters tape with the razor blade.
12. Remove the cleaning rod from the barrel.
13. Remove the bolt from the rifle.
14. Drop the bullet you wish to measure into the chamber, nose first.
15. Using the sharpened end of the pencil, push the bullet firmly against the rifling.
16. Re-insert the cleaning rod and jag until you feel it touch the nose of the bullet.
17. Repeat step 10 while holding the cleaning rod and jag in place against the nose of the bullet.
18. Remove the cleaning rod and jag assembly from the rifle barrel.
19. Remove the pencil and bullet from the chamber of the rifle barrel.
20. Remove the excess painters tape at each end of the line of tape that was applied to the cleaning rod. There should now remain a piece of tape that has been squarely cut at each end.
21. Measure the remaining tape on the cleaning rod with a set of calipers.
22. The result is the OAL to the rifling, with the specific bullet you placed in the chamber.



[RichieG]

I have had good results with 43Gr of H4350 & 175Gr Speer Grand Slam in the past. Please substitute the Speer Grand Slam with your Hornady ELD-X 175Gr Red Tip and let me know your results.

I used this recipe (43.0 and 43.1) behind the 175gr ELDX and it is accurate in my rifle with is a modern .275 Rigby. It is at the higher end of pressure (though the rigby does have a long throat) which isn't where I usually settle, so normal rules apply. Work up from much lower. The bullet was accurate across 90% charges weights in my rifle. Velocity was 2500fps which is a little fast for the softish eldx as a bushveld load, around 2300fps would be better. Good luck and stay safe.



[RayAtkinson]

Ive been shooting the 7x57 for over 70 years, and never found a better powder than H414 and WW760 is the same powder in a different can..start with book max and work up to your rifles max, keep in mind that most all 7x57 loads are way below max due to old 95 and 96 Mausers...My hunting load for deer size African antelope is 48 plus H414 and the 130 gr Speer FB or BTSP and the 160 gr Nosler Partition on elk size game...Loads quoted are for a strong 98 Mauser, win pre64 Rem 700 etc..



[hoytcanon]

Ive been shooting the 7x57 for over 70 years, and never found a better powder than H414 and WW760 is the same powder in a different can..start with book max and work up to your rifles max, keep in mind that most all 7x57 loads are way below max due to old 95 and 96 Mausers...My hunting load for deer size African antelope is 48 plus H414 and the 130 gr Speer FB or BTSP and the 160 gr Nosler Partition on elk size game...Loads quoted are for a strong 98 Mauser, win pre64 Rem 700 etc..

My load is 50.0 W760 with 150 grain bullets... lots of game taken out of several rifles.



[Warren Knudsen]

I load 45.7 w760 with fed 215m primer and 170g norma oryx for 2550fps



[Joker12]

I just picked up one of the Ruger #1’s in 275 Rigby and was wondering if I can use published load date for the 7x57. I’ll be using 7x57 brass until I can find some of the 275 brass.

Yes you can. There is really no need to use brass that is head stamped 275 Rigby, they are the same cartridge.



[Zkk93]

Hi,
I don't have the same rifle my rifle(Zkk 600) has the same twist:
I wasnt able to have a decent group with 175 grains round nose like but I have decent group suitable for hunting with factory Brenneke ammo loaded with 177 grains Tig.

I got best results with Nosler Ballistic Tip 140 grains matched with Norma 204 or for target shooting were very easy to set up Hornady Eld-M 162 grains.

For the COL, I followed the one suggested by Nosler manual and I have great results.



[Joker12]

My 7x57 is a Ruger #1A with a 22 inch barrel. It shoots 154gr Hornady interlocks beautiful. These rifles are long throated to handle the heavier bullets so you can seat the bullets out a ways. The load that I settled on is 50gr of IMR4831, Winchester LR primers and Winchester brass. In my rifle that gives sub MOA accuracy at 2725fps. Good luck with yours!



[hoytcanon]

I load 45.7 w760 with fed 215m primer and 170g norma oryx for 2550fps

P.S - 50.0 grains of RL-19 with 150/154's is also a very good 7X57 load.
